PVC injection molding machine LSF308

FOB Reference Price:Get Latest Price
US $11,500-130,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
50 Set/Sets per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
injection molding
Style:
Horizontal
Brand Name:
LONGSHUN
Model Number:
LSF308
Place of Origin:
Jiangsu, China (Mainland)
Plastic Type:
Thermoplastic
Automatic:
Yes
Injection Weight:
738-1004g
Injection Rate:
177-239g/s, 206g/s
Clamping Force:
3080KN
Opening Stroke:
590MM
Power(W):
36.4KW
Certification:
ISO9001
After-sales Service Provided:
Engineers available to service machinery overseas
Injection weight:
866g
Screw Speed:
185rpm
Clamp Force:
308ton
Space Between Tie Bars:
630*630mm
Toggle Stroke:
590mm
Max. Mold Height:
630mm
Min. Mold Height:
200mm
Machine Dimension(L*W*H):
6.15X1.57X2m
Machine Weight:
10.2T
Packaging & Delivery
Packaging Details
standard package
Delivery Time
20-25 days after payment

Specifications

1.energy saving with servo motor
2.fast respons
3.injection moulding machine
4.high precision, high stability
5.better price







Company Information
PVC injection molding machine LSF308

We are professional manufacturer of PVC injection molding machine in Changzhou City of China,the clamp force is from 68 ton to 1680ton .injection weight ranges from 60g to 10000g



Product Description





 Parameters of PVC injection molding machine LSF308

INJECTION UNIT

item

unit

LSF308

A

B

C

screw diameter

mm

60

65

70

screw L/D ratio

L/D

21.6

20

18.6

theoretical shot size

cm3

811

952

1104

injection weight

g

738

866

1004

Injection rate

g/s

177

206

239

Plasticizing capacity

g/s

41

49

57

Injection pressure

Mpa

193

164

142

Screw speed

rpm

0-185

CLAMPING UNIT

Clamp force

KN

3080

Space between tie bars

mm

630*630

Toggle stroke

mm

590

Max. mold height

mm

630

Min. mold height

mm

200

Ejector stroke

mm

160

Ejector tonnage

KN

62

Ejector number

p

9

OTHERS

Max.pump pressure

Mpa

16

Pump motor power

KW

30

Heater power

KW

18

Machine dimension

m

6.15*1.57*2

Machine weight

t

10.2



Introduction:



1. We design,manuafcture and supply our own brand of injection moulding machine called “Longsheng” with clamping force ranged from 680kn to 16800kn, injection weight from 63g to 10000g, and can provide custom-built machine







2.our injection moulding machine is desiged to Inject all kinds of plastic parts, bottle preform, engineering plastic, UPVC, PVC, PE pipes fitting, pomponents for automotive, household, eletronics,  telecommunication, ETC



Advantages:





 Control part:



1.It adopts imported computer for plastic injection machine , with large screen . high definiyion crystal display and human-computer interface in different languages. Through CPU independent control and individual treatment. It has raised the running speed of thr control system and alarming of successive oil temperature , thus I,proving the operating speed of the machine.







2.Closed –loop temperature control system to ensure the accuracy and reliability of the barrel temperature . The functions of cold –proof boot, alarming and parameter memory for the molding, with password protection. The injection and switch are controlled by imported ruler.







 Injection part:



1.The excellent chrome , molybdenum and aluminum alloy screw and barrel have undergone the nitrilizing process, applicable to various plastic materials.







2.The injection cylinder(258T advanced)  is parallel or balance for both sides of the barrel, so as to ensure the non-deviation of thr nozzle, good sealing and non-leadage. It is equipped with double guide pillar supporting system which can inject under multifarious pressure at various speeds. It also uses one-stop hydraulic pre-injection device.











Hydralic part:



It adopts the imported top quality hydraulic components, proportional control for pressure and flow.







Mouding-adjusment part:



Mold is adjusted by gear controlled by oil motor , the mold can be adjusted automatically in accordance with the setting pressure , which is both convenient and reliable.







Mold part



1.Five –fulcrum crankshaft structure , the mold and bracket structure together,with good rigidity and high-fitting precision, adopting the computerized optimized design. The mold employs finite element analysis, with double pulling and inserting device.



2.Perfroms thefunctions of super sensitive low pressure protection. The mechnical hydraulic and electrical protection have the human safety. The dismounable fill-out hopper can be installed conveniently and automatically.The moveable platen adopts a fixed durable vertical brace that is adjustable. With little friction and balanced dependable moving. Clamp opening is synchro with ejection.
